100KW High Frequency Induction Heating Equipment With Water cooling system

100KW High Frequency Induction Heating Equipment With Water cooling system
100KW High Frequency Induction Heating Equipment With Water cooling system

Large Image :  100KW High Frequency Induction Heating Equipment With Water cooling system

Product Details:
Place of Origin: China
Brand Name: GY
Certification: CE, ROHS, SGS
Model Number: GY-100AB
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: wooden box
Delivery Time: Depend on the order and destination
Payment Terms: T/T
Supply Ability: 500set/month

100KW High Frequency Induction Heating Equipment With Water cooling system

Description
High Light:

induction heating apparatus

,

induction heating apparatus



100KW High Frequency Induction Heating Equipment With Water cooling system





Quick Details



Place of Origin: Guangdong, China(Mainlan)

Brand Name: GY

Model Number:GY-100AB

After-sales Service Provided: Enigneers available to service machinery overseas

Input power: Three phase 340V-430V

Input current: 150A

Output current:400-4000A





Specification



Model

GY-100AB (Three phase)

work power

360V-520V

input current

150A

Fluctuating output power

100KW

fluctuating frequency

30-80KHZ

output current

400-4000A

the flow rate of cooling water

0.08-0.16Mpa 10L/Min

water temperature protection point

40C

product size

main 820x600x1060mm

transformer 870*430*750mm

net weight

main 123kg

transformer 84kg





Characteristics of  High Frequency Induction Heating Equipment



  1. Small size, light weight
  2. Save electric .can save 20% electric than KGPS furnace. can save 50% electric than gas/coal/coke furnace
  3. Furnace have electromagnetic auto-stir function, gold liquid will be evenly after melting
  4. Furnace installed temperature controller. temperature controller will control and show temperature. furnace will stop heating and keep temperature after reach at requirement temperature
  5. Machine have over current, over voltage, over hot, lack water warning system.
  6. Furnace easy to operation and installation
  7. Our melting furnace special working in jewelry field, laboratory, gold melting factory, mining industry. etc
  8. Melting time will be around 10 minutes.





Main characteristics

  1. Adoping MOSFGT and IGBT inverting device, tracking frequency automaticall
  2. High frequency, heated quickly, its powei consumption is only 20%~30% of eletronic tube induction heating machine and other heating style.
  3. Security and reliability, the equipments have the secure voltage and it's secure to operate
  4. Manual, automatic regulating automatically, it can protect itself from over voltage, over current, lack of water, phase fail, over hot, etc
  5. It has no open-fire, noise and pollution, be suit for the environmental protection and fire, improve the image of the company
  6. Recommend usage: Weld, forging, hot cooperate, melting, quenching, anneat etc





   Advantages:

  1.  Energy saving, Environmental protection, Low pollution level
  2.  Miniature and light weight, Economic Space Occupation, Easy installation
  3.  Enhanced monitoring and diagnostics system—"GY" device, guarantee the machine    of high stability, reliability and security.
  4.  Strict Supplier Management System and ISO9001-2008 Quality Management System guarantee high quality of each equipment.
  5.  CE certification
  6.  Customized services, which made machines as per customer's requirement



100KW High Frequency Induction Heating Equipment With Water cooling system 0
