Product Details:
|
| Application: | Online Annealling, Hardening, Melting | ||
|---|---|---|---|
| High Light: | induction heating apparatus,induction heating apparatus |
||
Technical parameter :
| Model | GY-15AB (Single phase) |
| work power | 180V-250V |
| input current | 35A |
| Fluctuating output power | 15KW |
| fluctuating frequency | 30-100KHZ |
| output current | 200-600A |
| the flow rate of cooling water | 0.06-0.12Mpa 7.5L/Min |
| water temperature protection point | 40C |
| product size | main : 530x225x450mm |
| transformer : 370x210x370mm | |
| net weight | main : 18kg |
| transformer : 15kg |
Major Scope of Application:
Quench for shaft, gear and inner hole of mold, quenching depth can be within 2mm.
Carbon steel and stainless steel screw coating
Continuously quench for saw blade, anneal and quench for stainless steel, alloy steel thread.
Welding for hard alloy saw blade, reamer, communication cable joint, and filter capacitor.
Welding for joint of metal tube, and continuous welding of stop valve.
Main features:
This equipment adopts Soft-switch ultrahigh frequency technology and two poles closed loop control technology; and our company fully owns the independent intellectual property rights
Fluctuating frequency can be 100K-1.5MHZ, effectively control the depth of surface quenching, which can totally replace the high frequency of vacuum tube.
It can continuously work for 24 hours, and 100% duty cycle.
It had adopt Well-know brand accessories.
Ultra-small size and weight; High efficiency, energy saving and environmental protection with safety.
